Chetan Steel, a reputed manufacturer and supplier in Delhi, India, offers premium Alloy Steel Grade 22 Coils engineered for high-performance industrial applications. Known for their consistent quality, excellent surface finish, and dimensional accuracy, these coils reflect Chetan Steel’s commitment to delivering reliable steel solutions. Alloy Steel Grade 22 Coils are widely used in high-temperature and high-strength applications, providing excellent mechanical performance and durability. With strict adherence to international standards and rigorous quality control, Chetan Steel ensures that every coil meets the demanding requirements of engineering, power, and industrial sectors, delivering long-lasting and dependable performance.
Alloy Steel Grade 22 Coils are primarily composed of 0.10–0.15% carbon, 0.25–0.50% manganese, 0.25–0.40% silicon, 2.00–2.50% chromium, and 0.50–0.80% molybdenum, with trace amounts of phosphorus and sulfur (<0.035%). This composition provides high tensile strength, toughness, and excellent resistance to high-temperature creep. Mechanically, these coils offer a tensile strength of 620–850 MPa and yield strength of 415–600 MPa. They are suitable for hot and cold working, welding, and forming, making them ideal for boiler tubes, pressure vessels, and high-temperature industrial applications.
| Specifications | : | ASTM A387 / ASME SA387 |
| Thickness | : | 1mm-300mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, 4050mm etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, 12000mm, 15000mm etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| Alloy Steel Gr 22 | 0.05 – 0.15 | 0.30-0.60 | 0.50 max | 0.035 max | 0.035 max | 2.0 – 2.5 | 0.90 – 1.10 | – | – |
| Tensile (MPa) | Yield (MPa) | Elongation (50mm) | Elongation (200mm) | Reduction of Area |
| 415 – 585 | 205 min | 18% min | – | 40% min |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Chetan Steel based in Delhi, India is a trusted manufacturer and supplier for Alloy Steel Grade 22 Coil of great quality. In fact, we have earned our reputation for providing a variety of top-notch steel products-such as Structural Steel, Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel-with emphasis on Structural Steel Sheets and Plates. Basic product lines include a complete range of Pipes, Tubes, Flanges, Forged Fittings, Bars, and other forms. Chetan Steel is committed to its delivery and customer service, thus ensuring that they procure the best raw materials to guarantee high strength and durability with performance specifically for critical industrial applications. Contact us anytime for your Structural Steel Sheet and Plate needs!
Alloy Steel Grade 22 Coils are extensively used in power generation, petrochemical, and boiler industries due to their high-temperature strength and excellent creep resistance. They are ideal for manufacturing boiler tubes, heat exchangers, pressure vessels, and piping systems operating under high stress and temperature. These coils are also employed in heavy engineering applications, including industrial machinery and structural components where durability and mechanical performance are critical. With their superior corrosion resistance, toughness, and weldability, Alloy Steel Grade 22 Coils are a preferred choice for engineers and fabricators seeking reliable, high-performance steel solutions for demanding industrial applications.
