Chetan Steel stands out as a trusted manufacturer and supplier based in Delhi, specializing in high-quality Carbon Steel BS 6323 Pipes tailored for precision mechanical and engineering needs. With state-of-the-art manufacturing and testing facilities, the company guarantees pipes that meet BS standards and cater to specific customer requirements. Chetan Steel’s BS 6323 pipes are known for their excellent dimensional accuracy, smooth surface finish, and reliable mechanical performance. Serving a variety of industries, including automotive, machinery manufacturing, construction, power generation, and general engineering, the company is recognized for its competitive pricing, dependable quality, and timely delivery, making it a go-to source for BS 6323 carbon steel pipe solutions.
Carbon Steel BS 6323 Pipes are crafted from top-notch carbon steel, featuring carefully controlled levels of carbon, manganese, silicon, sulfur, and phosphorus. This well-balanced composition provides impressive strength, toughness, and machinability. Mechanically, these pipes deliver dependable tensile and yield strength, along with good elongation and impact resistance. They maintain uniform hardness and respond effectively to heat treatment processes like normalizing. BS 6323 pipes ensure dimensional stability and consistent mechanical properties, making them perfect for precision engineering and load-bearing applications.
|
Grade |
Mfg. Process |
Chemical Composition(%) | ||||||||
|
C |
Si |
Mn |
P |
S |
Ni |
Cr |
Mo |
Others |
||
|
BW320 |
B |
0.16Max |
– |
0.30~0.70 |
0.040Max |
0.040Max |
– |
– |
– |
– |
|
ERW320 |
E |
0.16Max |
– |
0.30~0.70 |
0.040Max |
0.040Max |
– |
– |
– |
– |
|
ERW360 |
E |
0.17Max |
0.35Max |
0.40~0.80 |
0.040Max |
0.050Max |
– |
– |
– |
– |
|
ERW430 |
E |
0.21Max |
0.35Max |
0.40~1.20 |
0.040Max |
0.040Max |
– |
– |
– |
– |
|
S360 |
S |
0.17Max |
0.35Max |
0.40~0.80 |
0.040Max |
0.040Max |
– |
– |
– |
t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
|
S430 |
S |
0.21Max |
0.35Max |
0.40~1.20 |
0.040Max |
0.040Max |
– |
– |
– |
t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
|
SAW430 |
A |
0.25Max |
0.50Max |
1.20Max |
0.040Max |
0.040Max |
– |
– |
– |
t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
Grade
| Tensile Test MPa or N/mm2 | Remaks (Similar to JIS) | Possibility Temperature | |
Min Yield point | Tensile Strength | |||
BW320 | 195 | 320~460 | – | |
ERW320 | 195 | 320~460 | – | |
ERW360 | 235 | 360~500 | (STPG370) | |
ERW430 | 195 | 430~570 | (STPG410) | |
S360 | 235 225 215 | 360~550 | (STPG310) | |
S430 | 275 265 255 | 430~570 | (STPG410) | |
SAW430 | 275 265 255 | 430~570 | (STPY400) | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Outer diameter and wall Thickness | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Execution | Size Range | OD Tolerance | Wall tolerance | ||||||
| Hot-rolled Tube | OD – 80 mmOD > 80 mmWall < 12 mmWall – 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wallthickness + 0.1 mm | ||||||
| Hot-rolled peeled tube | All sizesWall < 12 mmWall – 12 mm | + 0.25/- 0 mm | ± 0.8 mm± (5 % x wall thickness+ 0.2 mm) | ||||||
| Cold Worked tubecold-rolled or cold-drawn | OD < 40 mmOD 40 – 80 mmOD > 80 Wall Thickness< 6 mm Wall Thickness6 – 8 mm Wall Thickness > 8 | + 0.30/- 0 mm*+ 0.35/- 0 mm*+ 0.40/- 0 mm* | ± 0.30 mm± 0.35 mm± 0.40 mm | ||||||
Chetan Steel is a leading manufacturer and supplier of high-quality Carbon Steel BS6323 Pipe products in Delhi, India. Specializing in steel solutions, we offer a wide range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product lineup includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Known for our reliable delivery and exceptional customer service, we are committed to providing top-grade steel materials that ensure durability and performance across diverse industrial applications. Chetan Steel is your trusted partner for all your Carbon Steel BS6323 Pipe needs.
Carbon Steel BS 6323 Pipes find extensive use in applications that demand precision, strength, and durability. They are frequently utilized in the automotive and engineering sectors for crafting mechanical components, shafts, and structural parts. Additionally, these pipes play a vital role in machinery manufacturing, fabrication, and power transmission systems. In construction and industrial projects, BS 6323 pipes provide essential support for frameworks and load-bearing structures. Their excellent machinability, robust strength, and consistent performance make them an ideal choice for general engineering applications.
