Chetan Steel is a dependable manufacturer and supplier in Delhi, offering precision-engineered carbon steel pipes for mechanical and engineering applications. With a strong emphasis on quality, consistency, and compliance with European standards, the company delivers materials that perform reliably in real-world conditions. Carbon Steel EN 10083-2 Grade C22R Pipes are low-carbon steel pipes known for their good formability, machinability, and balanced strength. Manufactured under strict quality control, these pipes provide dimensional accuracy, durability, and long service life across diverse industrial environments.
Carbon Steel EN 10083-2 Grade C22R Pipes are produced from low-carbon steel with carefully controlled chemical composition. These pipes offer good yield strength, moderate tensile strength, and excellent ductility. The refined microstructure supports easy machining, welding, and forming while maintaining structural stability. Designed for mechanical and light structural applications, Carbon Steel C22R Pipes deliver consistent mechanical performance and reliable toughness under normal working loads.
| Specification | Details |
|---|---|
| Material | EN 10083-2 Grade C22R Carbon Steel |
| Product | Seamless Pipes and Tubes |
| Carbon Content | Max 0.20% |
| Manganese Content | 0.50% – 1.40% |
| Characteristics | – Low-Cost: Cost-effective option for low-carbon steel pipes – Formability: Easy to form and shape – Surface Hardness: Not as hard as high carbon steel pipes, but can be – increased through carburizing |
| Standard | Manufactured as per EN 10083-2 specification |
| Commercial Reference | Referred to as CS (carbon steel) pipes or MS (mild steel) pipes |
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
| 0.17-0.24 | max 0.40 | 0.40-0.70 | 0.045 | 0.045 | max 0.10 | max 0.40 | max 0.40 | – | – |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
|  |  | 430 | – | – | 24 |
| DIN | EN | BS | NFA | ASTM | ASME |
|---|---|---|---|---|---|
| DIN 17204 Grade Cm22 | EN 10083-2 Grade C22R | – | ASTM A519 Grade 1021 | ASME SA 519 Grade 1021 | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Chetan Steel is a trusted manufacturer and supplier of high-quality Carbon Steel EN 10083-2 Grade C22R Pipe products in Delhi, India. Specializing in premium steel materials, we offer a comprehensive range, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to reliable delivery and exceptional customer service, Chetan Steel provides top-grade materials that ensure superior performance across various industrial applications. Trust Chetan Steel for all your Carbon Steel EN 10083-2 Pipe needs.
| Execution | Size Range | OD Tolerance | Wall tolerance |
|---|---|---|---|
| Hot-rolled Tube | OD – 80 mmOD > 80 mmWall < 12 mmWall – 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wallthickness + 0.1 mm |
| Hot-rolled peeled tube | All sizesWall < 12 mmWall – 12 mm | + 0.25/- 0 mm | ± 0.8 mm± (5 % x wall thickness+ 0.2 mm) |
| Cold Worked tubecold-rolled or cold-drawn | OD < 40 mmOD 40 – 80 mmOD > 80 Wall Thickness < 6 mm Wall Thickness6 – 8 mm Wall Thickness > 8 | + 0.30/- 0 mm*+ 0.35/- 0 mm*+ 0.40/- 0 mm* | ± 0.30 mm± 0.35 mm± 0.40 mm |
Carbon Steel EN 10083-2 Grade C22R Pipes are widely used in mechanical engineering, automotive components, and general fabrication work. They are commonly applied in shafts, bushings, sleeves, brackets, and lightly loaded machine parts. These pipes are suitable for applications requiring good formability and dependable strength. Preferred by manufacturers and fabricators, Carbon Steel C22R Pipes provide cost-effective performance, reliability, and versatility across a wide range of industrial and engineering uses.
