Chetan Steel, is a famous producing and distributing corporation based in the India Delhi. Chetan produces first-class products used in diverse applications, particularly a Low Temperature Carbon Steel A333 Gr 1 Pipe which promises superior service life in extremely cryogenic as well as in severely low temperatures, while committedly to accurate engineering and exact standards of quality and durability of pipeline solutions especially intended for harsh duty applications. Leveraged by clients all around the world, the company is a leader in producing innovative steel products that meet the most demanding industrial requirements.
Low Temperature Carbon Steel A333 Gr 1 Pipe is primarily composed of carbon and manganese combined with trace elements for excellent performance under low temperatures. It has great toughness, impact strength, and durability in environments down to -50°F (-46°C). The following are the mechanical properties: tensile strength at 380 MPa and yield strength at 205 MPa, showing resistance under pressure. All such pipes have better weldability properties, are economic, and resistant to cryogenic applications, suitable for industries based on petrochemical, gas processing, power generation, wherein low-temperature performance is imperative.
| Type | Seamless / SAW / ERW / Spiral weld / Fabricated / Welded |
|---|---|
| Grade | Low Temperature Seamless Pipe: ASTM A333 Gr. 1 |
| Outer Dimensions | 19.05mm-457mm |
| Wall Thickness | 2.0mm-60mm |
| Lengths | required shall be specified on order.If no definite lengths required, following practice applies: |
| Single Random | 17′ ~ 24′ lengths |
| Double Random | 36′ ~ 44′ lengths |
| Additional Testing | NACE MR0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, etc. |
| Compositions | Data |
|---|---|
| Carbon(max.) | 0.30 |
| Manganese | 0.40–1.06 |
| Phosphorus(max.) | 0.025 |
| Sulfur(max.) | 0.025 |
| Silicon | … |
| Nickel | … |
| Chromium | … |
| Other Elements | … |
| Properties | Data |
|---|---|
| Yield strength(min) | 205Mpa |
| Tensile strength(min) | 380Mpa |
| Elongation(%) | 35 |
| Nominal | OD mm | Pipe size | Sch. 30 | Sch20 | Schedule 40 | Sch.STD | Sch 60 | Strong (XS) | Schedule Extra | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Mm | Inch | Wall | Wt. | Wall | Wt. | Wall | Wt. | Wall | Wt. | Wall | Wt. | Wt. | Wall | |
| 3 | 10.3 | 1/8 | 1.73 | 0.357 | 1.73 | 0.37 | 0.47 | 2.41 | ||||||
| 6 | 13.7 | ¼ | 2.24 | 0.625 | 2.24 | 0.63 | 0.804 | 3.02 | ||||||
| 10 | 17.1 | 3/8 | 2.31 | 0.84 | 2.31 | 0.84 | 1.1 | 3.2 | ||||||
| 15 | 21.3 | ½ | 2.77 | 1.26 | 2.77 | 1.26 | 1.62 | 3.73 | ||||||
| 20 | 26.7 | ¾ | 2.87 | 1.68 | 2.87 | 1.69 | 2.2 | 3.91 | ||||||
| 25 | 33.4 | 1 | 3.38 | 2.5 | 3.38 | 2.5 | 3.24 | 4.55 | ||||||
| 32 | 42.2 | 11/4 | 3.56 | 3.38 | 3.56 | 3.39 | 4.47 | 4.85 | ||||||
| 40 | 48.3 | 11/2 | 3.68 | 4.05 | 3.68 | 4.05 | 5.41 | 5.08 | ||||||
| 50 | 60.3 | 2 | 3.9 | 5.44 | 3.9 | 5.44 | 7.48 | 5.5 | ||||||
| 65 | 73 | 21/2 | 5.16 | 8.63 | 5.2 | 8.63 | 11.41 | 7 | ||||||
| 80 | 88.9 | 3/8 | 5.5 | 11.3 | 5.5 | 11.3 | 15.3 | 7.62 | ||||||
| 90 | 1.6 | 31/2 | 5.74 | 13.57 | 5.74 | 13.57 | 18.63 | 8.08 | ||||||
| 100 | 114.3 | 4 | 6.02 | 16.07 | 6.02 | 16.07 | 22.3 | 8.56 | ||||||
| 125 | 141.3 | 5 | 6.55 | 21.77 | 6.6 | 21.77 | 30.9 | 9.53 | ||||||
| 150 | 168.3 | 6 | 7.11 | 28.26 | 7.11 | 28.26 | 42.5 | 10.97 | ||||||
| 200 | 219.1 | 8 | 7 | 36.8 | 6.35 | 33.3 | 8.2 | 42.5 | 8.2 | 42.5 | 10.3 | 53.1 | 64.6 | 12.7 |
| 250 | 273 | 10 | 7.8 | 51.3 | 6.35 | 41.7 | 9.27 | 60.3 | 9.27 | 60.3 | 12.7 | 81.5 | 81.5 | 12.7 |
| 300 | 323.9 | 12 | 8.4 | 65.2 | 6.35 | 49.7 | 10.3 | 79.7 | 9.53 | 73.8 | 14.3 | 109 | 97.4 | 12.7 |
| 350 | 355.6 | 14 | 9.53 | 81.3 | 7.92 | 68.1 | 11.13 | 94.3 | 9.53 | 81.3 | 15.1 | 126.4 | 107 | 12.7 |
| 400 | 406.4 | 16 | 9.5 | 93.3 | 7.92 | 77.9 | 12.7 | 123 | 9.53 | 93.3 | 16.7 | 160 | 123 | 12.7 |
| 450 | 457.2 | 18 | 11.1 | 122 | 7.92 | 87.8 | 14.3 | 156 | 9.53 | 105 | 19 | 206 | 130 | 12.7 |
| 500 | 508 | 20 | 12.7 | 155.1 | 9.53 | 117.2 | 15.1 | 183 | 9.53 | 177.2 | 20.6 | 248 | 155.1 | 12.7 |
| 550 | 558.8 | 22 | 12.7 | 171 | 9.53 | 129 | 9.53 | 129 | 22.2 | 294 | 171 | 12.7 | ||
| 600 | 609.6 | 24 | 14.3 | 210 | 9.53 | 141 | 17.4 | 255 | 9.53 | 141 | 24.5 | 355 | 187 | 12.7 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Chetan Steel is a leading supplier of high-quality Low Temperature Carbon Steel A333 Gr 1 Pipe products in Delhi, India. We focus on steel solutions and offer a variety of products. This includes Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our products are Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. We are known for our good delivery and excellent customer care. We aim to provide strong and durable steel materials for many industrial uses. We work hard to meet high standards, making us a trusted partner for your steel needs.
The low-temperature carbon steel A333 Gr 1 pipe is often used where outstanding toughness properties must be at such low temperatures. It is the most used to build pipes, pipelines that can transport liquefied gas as LNG and LPG as well as any cold liquid, like those needed by the petrochemical and oil and gas, power plant and refrigeration sectors. It is also suitable for pressure vessel fabrication and other engineering purposes where resilience under extreme cold is essential. Its reliability and durability make it ideal for harsh environments and critical applications.
Chetan Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Delhi, India.
